Music Cue Sheets

Quick Start (Convert file)

This Endpoint can be used to quickly convert a sequence file from an NLE into a music cue sheet document. It only converts the file and does not create a new project that can be edited later. It's a simple way to convert EDL, XML, or other sequence formats into tables like Excel or CSV. You can find more details about the tool here: Music Cue Sheet (Converter)

(i) This Endpoint will not add any metadata from Production Music Libraries.

Endpoint

This endpoint is used to convert a file.

POST https://api.editingtools.io/v2/cuesheet

Authentication

This API requires Basic Authentication. The "Authorization" header should be set with the Base64 encoded string of "apikey:YOUR_API_KEY".

Authorization: Basic <base64Encoded(apikey:YOUR_API_KEY)>

Headers

Request Body

The API supports file uploads using a multipart/form-data request. The request can contain the following parameters:

cURL Examples

The following examples show how to use the API with cURL commands. If you are using a different language, we recommend using https://curlconverter.com to convert the commands for other languages like: PHP, JavaScript, Python, Ruby, Rust, Ansible, C , C#, ColdFusion, Clojure, Dart, Elixir, Go, HAR, HTTP, HTTPie, Java, JSON, Kotlin, MATLAB, Node.js, Objective-C, OCaml, PowerShell, R, Swift and more.

cURL Request Example 1

This is an example of how to convert a simple .edl with 25 fps file into a CSV document.

curl -X POST https://api.editingtools.io/v2/cuesheet \
-u "apikey:YOUR_API_KEY" \
-F file=@/Users/path/Demo_Sequence_25fps.edl \
-F framerate=25 \
-F format=csv \
-F mergeOverlappingClips=true

cURL Request Example 2

This is an example of how to convert a .edl sequence with 23.976 fps into an Excel spreadsheet in CISAC Standard.

curl -X POST https://api.editingtools.io/v2/cuesheet \
-u "apikey:YOUR_API_KEY" \
-F file=@/Users/path/Demo_Sequence_25fps.edl \
-F framerate=23.976 \
-F format=xlsx \
-F preset=cisac_preset \
-F mergeOverlappingClips=true

cURL Request Example 3

This is an example of how to convert a .edl sequence with 29.97 drop frame into an Excel spreadsheet and return the file as base64 string.

curl -X POST https://api.editingtools.io/v2/cuesheet \
-u "apikey:YOUR_API_KEY" \
-F file=@/Users/path/Demo_Sequence_25fps.edl \
-F framerate=29.97DF \
-F format=xlsx \
-F base64=true

Demo File

Demo sequence file (.edl) to test requests: Demo_Sequence_25fps.edl

Responses

Success (HTTP 200 OK)

If the file was successfully uploaded and the process started, the API will return a 200 OK status code with a JSON object containing the file details.

{
    "code": 200,
    "status": "The sequence was successfully converted into a music cue sheet document.",
    "timestamp": "2025-05-01T10:00:00Z",
    "data": {
    	"fileName": "Demo_Sequence_25fps.csv",
        "fileUrl": "https://editingtools.io/download/demo/path/Demo_Sequence_25fps.csv",
        "fileBase64": "Tm8uLFRpbWVjb2Rl...IsIiIK",
        "fileSize": 1830,
        "fileChecksum": "06abe8b0662afabe9ba8e1f0b0efe0b7"
    }
}

Error Responses

Error responses typically include an appropriate HTTP status code and a JSON body containing an error message.

{
    "code": "400",
    "status": "The upload could not be completed."
}

Download File

After the conversion is successfully completed, the file can be downloaded using the values returned under fileUrl and fileName.

cURL Request Example (macOS or Linux)

Example to download the file to the Desktop. Uses -o to specify the output file path.

curl -o ~/Desktop/{fileName} "{fileUrl}"

curl -o ~/Desktop/Demo_Sequence_25fps.csv "https://editingtools.io/download/demo/path/Demo_Sequence_25fps.csv"

cURL Request Example (Windows with PowerShell)

curl -o "$env:USERPROFILE\Desktop\{fileName}" "{fileUrl}"

curl -o $env:USERPROFILE\Desktop\Demo_Sequence_25fps.csv "https://editingtools.io/download/demo/path/Demo_Sequence_25fps.csv"

cURL Request Example (Windows Command Prompt with cURL installed)

curl -o "%USERPROFILE%\Desktop\{fileName}" "{fileUrl}"

curl -o %USERPROFILE%\Desktop\Demo_Sequence_25fps.csv "https://editingtools.io/download/demo/path/Demo_Sequence_25fps.csv"

Python3 Request Example

import os
import urllib.request

name = "Demo_Sequence_25fps.csv"
url = "https://editingtools.io/download/demo/path/Demo_Sequence_25fps.csv"

# Construct the path to the Desktop for example
local_path = os.path.join(os.path.expanduser("~"), "Desktop", name)

# Download the file
try:
    urllib.request.urlretrieve(url, local_path)
    print(f"File downloaded successfully and saved to: {local_path}")
except Exception as e:
    print(f"Failed to download file: {e}")

wget Request Example (macOS or Linux)

Example to download the file to the Desktop. Uses -O to specify the output file path.

wget -O ~/Desktop/{fileName} "{fileUrl}"

wget -O ~/Desktop/Demo_Sequence_25fps.csv "https://editingtools.io/download/demo/path/Demo_Sequence_25fps.csv"

wget Request Example (Windows with PowerShell)

wget -O "$env:USERPROFILE\Desktop\{fileName}" "{fileUrl}"

wget -O "$env:USERPROFILE\Desktop\Demo_Sequence_25fps.csv" "https://editingtools.io/download/demo/path/Demo_Sequence_25fps.csv"

wget Request Example (Windows Command Prompt with wget installed)

wget -O "%USERPROFILE%\Desktop\{fileName}" "{fileUrl}"

wget -O "%USERPROFILE%\Desktop\Demo_Sequence_25fps.csv" "https://editingtools.io/download/demo/path/Demo_Sequence_25fps.csv"

Create Project

This endpoint is used to create a new cue sheet project for the Music Cue Sheet Manager on the server.

Endpoint

POST https://api.editingtools.io/v2/cuesheets/project

Authentication

This API requires Basic Authentication. The "Authorization" header should be set with the Base64 encoded string of "apikey:YOUR_API_KEY".

Authorization: Basic <base64Encoded(apikey:YOUR_API_KEY)>

Headers

Request Body (JSON)

The request body should be a UTF8 JSON object containing the following parameters:

Example Request Body 1 - only required parameters

Create a new music cue sheet project without any music track entries.

{
    "name": "My New Cue Sheet Project"
}

Example Request Body 2 - with music tracks

Create a new music cue sheet project with music track entries.

{
    "name": "My New Cue Sheet Project",
    "color": "green",
    "framerate": "23.976",
    "entries" : [
    	{"filename" : "mysong.mp3", "timecodeIn" : "10:02:12:03", "timecodeOut" : "10:02:16:12" },
    	{"filename" : "song_2.mp3", "timecodeIn" : "10:03:20:01", "timecodeOut" : "10:04:23:21" }
    ]
}

cURL Examples

The following examples show how to use the API with cURL commands. If you are using a different language, we recommend using https://curlconverter.com to convert the commands for other languages like: PHP, JavaScript, Python, Ruby, Rust, Ansible, C , C#, ColdFusion, Clojure, Dart, Elixir, Go, HAR, HTTP, HTTPie, Java, JSON, Kotlin, MATLAB, Node.js, Objective-C, OCaml, PowerShell, R, Swift and more.

cURL Request Example 1 - only required parameters

curl -X POST https://api.editingtools.io/v2/cuesheets/project \
  -u "apikey:YOUR_API_KEY" \
  -H "Content-Type: application/json" \
  -d '{
    "name": "My New Cue Sheet Project"
}'

cURL Request Example 2 - with cues

curl -X POST https://api.editingtools.io/v2/cuesheets/project \
  -u "apikey:YOUR_API_KEY" \
  -H "Content-Type: application/json" \
  -d '{
  	"name": "My New Cue Sheet Project",
    "color": "green",
    "framerate": "23.976",
    "entries" : [
    	{"filename" : "mysong.mp3", "timecodeIn" : "10:02:12:03", "timecodeOut" : "10:02:16:12" },
    	{"filename" : "song_2.mp3", "timecodeIn" : "10:03:20:01", "timecodeOut" : "10:04:23:21" }
    ]
}'

Responses

Success (HTTP 201 Created)

If the request is successful, the API will return a 201 Created status code with a JSON object containing project details. The JSON will contain some informations.

Example

{
    "code": "201",
    "status": "The project was successfully created.",
    "timestamp": "2025-01-01T19:10:00Z",
    "data": {
        "projectId": "rcwo9binm0xo8wt9vpfz16pt5pypju",
        "creationDate": "2025-01-01T19:10:00Z"
    }
}

Error Responses (Example)

Error responses will typically include an appropriate HTTP status code (e.g., 400 Bad Request, 401 Unauthorized) and a JSON body with an error message.

It's recommended that the content of the "status" field be shown to end users as it can contain useful information. For example, it could be shown in an error dialog.

{
    "code": "400",
    "status": "Missing required parameter: name",
    "timestamp": "2025-01-01T19:10:00Z"
}

{
    "code": "401",
    "status": "Invalid API Key",
    "timestamp": "2025-01-01T19:10:00Z"
}

Duplicate Project

This endpoint is used to duplicate an existing music cue sheet project on the server. The project is identified by its projectId in the URL path.

Endpoint

POST https://api.editingtools.io/v2/cuesheets/project/{projectId}/copy

Replace {projectId} with the project's unique ID.

Authentication

This API requires Basic Authentication. The "Authorization" header should be set with the Base64 encoded string of "apikey:YOUR_API_KEY".

Authorization: Basic <base64Encoded(apikey:YOUR_API_KEY)>

Headers

Path Parameters

Request Body (JSON)

The request body should be a UTF8 JSON object containing the following parameters:

Example Request Body

Duplicate a project with all music track entries.

{
    "name": "My New Cue Sheet Project (Copy)",
    "copyEntries": true
}

cURL Request Example

Replace {projectId} with the project id.

curl -X POST https://api.editingtools.io/v2/cuesheets/project/{projectId}/copy \
  -u "apikey:YOUR_API_KEY" \
  -H "Content-Type: application/json" \
  -d '{
    "name": "My New Cue Sheet Project (Copy)",
    "copyEntries": true
}'

Responses

Success (HTTP 201 Created)

If the request is successful, the API will return a 201 Created status code with a JSON object containing project details. The JSON will contain some informations.

Example

{
    "code": "201",
    "status": "The music cue sheet has been duplicated successfully.",
    "timestamp": "2025-01-01T19:10:00Z",
    "data": {
        "projectId": "rcwo9binm0xo8wt9vpfz16pt5pypju",
        "creationDate": "2025-01-01T19:10:00Z"
    }
}

Error Responses (Example)

Error responses will typically include an appropriate HTTP status code (e.g., 400 Bad Request, 401 Unauthorized, 404 Not found) and a JSON body with an error message.

It's recommended that the content of the "status" field be shown to end users as it can contain useful information. For example, it could be shown in an error dialog.

{
    "code": "400",
    "status": "Please enter a project name with at least 3 characters.",
    "timestamp": "2025-01-01T19:10:00Z"
}

Get Projects (List)

This endpoint allows to get a list of all music cue sheet project connected to the API account on EditingTools.io.

Endpoint

GET https://api.editingtools.io/v2/cuesheets/projects

Headers

cURL Request Example 1

curl -X GET https://api.editingtools.io/v2/cuesheets/projects \
   -u "apikey:YOUR_API_KEY"

Responses

Success (HTTP 200 OK)

If the projects were successfully loaded, the API will return a 200 OK status code with a JSON object containing all existing projects.

Example

{
    "code": "200",
    "status": "The projects were successfully loaded.",
    "data": [
        {
            "projectId": "6u00p3lz1ycwixs3g2kq0nx3qkroskxiw8o578wx99dor8zn",
            "name": "Late Night Show - Episode 38",
            "color": "green",
            "lastUpdate": "2025-05-17T09:17:52Z",
            "createdDate": "2025-05-01T08:20:00Z"
        },
        {
            "projectId": "nz1thfewx86pirs8etj51huxnfk6sbaytmlb62lghyt64kvs",
            "name": "Late Night Show - Episode 37",
            "color": "blue",
            "lastUpdate": "2025-05-12T10:00:34Z",
            "createdDate": "2025-05-02T10:20:52Z"
        }
    ]

}

Error Responses

Error responses will typically include an appropriate HTTP status code and a JSON body with an error message.

{
    "code": "400",
    "status": "The projects could not be loaded."
}

Get Project (Details)

This endpoint allows to get details of a selected project. The projectId have to be specify directly in the URL path.

Endpoint

GET https://api.editingtools.io/v2/cuesheets/project/{projectId}

Replace {projectId} with the project's unique ID.

Headers

Path Parameters

cURL Request Example 1

curl -X GET https://api.editingtools.io/v2/cuesheets/project/{project_id} \
   -u "apikey:YOUR_API_KEY"

Responses

Success (HTTP 200 OK)

If the project was successfully loaded, the API will return a 200 OK status code with a JSON object.

Example

{
    "code": "200",
    "status": "The projects were successfully loaded.",
    "data": {
        "projectId": "6u00p3lz1ycwixs3g2kq0nx3qkroskxiw8o578wx99dor8zn",
        "name": "Late Night Show - Episode 38",
        "color": "green",
        "lastUpdate": "2025-05-17T09:17:52Z",
        "createdDate": "2025-05-01T08:20:00Z"
    }
}

Error Responses

Error responses will typically include an appropriate HTTP status code and a JSON body with an error message.

{
    "code": "404",
    "status": "The project with the chosen ID could not be found."
}

Delete Project

This endpoint is used to delete a project from server. The project is identified by its projectId in the URL path.

Endpoint

DELETE https://api.editingtools.io/v2/cuesheets/project/{projectId}

Replace {projectId} with the project's unique ID.

Headers

Path Parameters

cURL Request Example

curl -X DELETE https://api.editingtools.io/v2/cuesheets/project/{projectId} \
  -u "apikey:YOUR_API_KEY"

Replace {projectId} with the project id.

Responses

Success (HTTP 200 OK)

If the project was deleted successfully, the API will return a 200 OK status code with a JSON object confirming the deletion.

{
    "code": "200",
    "status": "The music cue sheet project has been successfully deleted.",
    "timestamp": "2025-01-01T19:10:00Z"
}

Error Responses

Error responses will typically include an appropriate HTTP status code and a JSON body with an error message.

{
    "code": "404",
    "status": "The project with the chosen projectId could not be found.",
    "timestamp": "2025-01-01T19:10:00Z"
}

Add entries

This endpoint is used to add new music track entries to an existing music cue sheet project. Existing entries will not be changed or deleted.

(!) The current limit is 100 new track entries per call. You may need multiple calls if you have more files to add.

Endpoint

POST https://api.editingtools.io/v2/cuesheets/project/{projectId}/entries

Replace {projectId} with the project's unique ID.

Authentication

This API requires Basic Authentication. The "Authorization" header should be set with the Base64 encoded string of "apikey:YOUR_API_KEY".

Authorization: Basic <base64Encoded(apikey:YOUR_API_KEY)>

Headers

Path Parameters

Request Body (JSON)

The request body should be a UTF8 JSON object containing the following parameters:

Example Request Body 1 - only required parameters

Create one new entry.

{
    "filename" : "mysong.mp3",
    "timecodeIn" : "10:02:12:03",
    "timecodeOut" : "10:02:16:12"
}

Example Request Body 2 - multiple entries

Create multiple new entry with different attributes.

[
    {
        "fileName": "intro_theme.mp3",
        "clipName": "Intro Theme",
        "timecodeIn": "00:00:00:00",
        "timecodeOut": "00:00:30:12",
        "duration": "00:00:30:12"
    },
    {
        "fileName": "dialogue_1.mp3",
        "clipName": "Opening Dialogue",
        "timecodeIn": "00:00:31:00",
        "timecodeOut": "00:01:15:00",
        "sourceIn": "00:00:00:00",
        "sourceOut": "00:00:44:00"
    },
    {
        "fileName": "transition_fx.mp3",
        "clipName": "Whoosh FX",
        "timecodeIn": "00:01:15:01",
        "timecodeOut": "00:01:16:10"
    }
]

cURL Examples

cURL Request Example 1 - only required parameters

curl -X POST https://api.editingtools.io/v2/cuesheets/project/{projectId}/entries \
  -u "apikey:YOUR_API_KEY" \
  -H "Content-Type: application/json" \
  -d '{
    "filename" : "mysong.mp3",
    "timecodeIn" : "10:02:12:03",
    "timecodeOut" : "10:02:16:12"
}'

cURL Request Example 2 - with cues

curl -X POST https://api.editingtools.io/v2/cuesheets/project/{projectId}/entries \
  -u "apikey:YOUR_API_KEY" \
  -H "Content-Type: application/json" \
  -d '[
    {
        "fileName": "intro_theme.mp3",
        "clipName": "Intro Theme",
        "timecodeIn": "00:00:00:00",
        "timecodeOut": "00:00:30:12",
        "duration": "00:00:30:12"
    },
    {
        "fileName": "dialogue_1.mp3",
        "clipName": "Opening Dialogue",
        "timecodeIn": "00:00:31:00",
        "timecodeOut": "00:01:15:00",
        "sourceIn": "00:00:00:00",
        "sourceOut": "00:00:44:00"
    },
    {
        "fileName": "transition_fx.mp3",
        "clipName": "Whoosh FX",
        "timecodeIn": "00:01:15:01",
        "timecodeOut": "00:01:16:10"
    }
]'

Responses

Success (HTTP 201 Created)

If the request is successful, the API will return a 201 Created status code with a JSON object containing project details. The JSON will contain some informations.

Example

{
    "code": "201",
    "status": "The music track entries have been successfully added to the project. (3/3)",
    "timestamp": "2025-01-05T10:08:00Z",
    "data": {
        "projectId": "rcwo9binm0xo8wt9vpfz16pt5pypju",
        "creationDate": "2025-01-01T19:10:00Z"
    }
}

Error Responses (Example)

Error responses will typically include an appropriate HTTP status code (e.g., 400 Bad Request, 401 Unauthorized) and a JSON body with an error message.

It's recommended that the content of the "status" field be shown to end users as it can contain useful information. For example, it could be shown in an error dialog.

{
    "code": "404",
    "status": "Project not found.",
    "timestamp": "2025-01-01T19:10:00Z"
}

Delete Project Entries

This endpoint is used to delete all music track entries in a project. The project itself will not be deleted. The project is identified by its projectId in the URL path.

Endpoint

DELETE https://api.editingtools.io/v2/cuesheets/project/{projectId}/entries

Replace {projectId} with the project's unique ID.

Headers

Path Parameters

cURL Request Example

curl -X DELETE https://api.editingtools.io/v2/cuesheets/project/{projectId}/entries \
  -u "apikey:YOUR_API_KEY"

Replace {projectId} with the project id.

Responses

Success (HTTP 200 OK)

If the project entries were deleted successfully, the API will return a 200 OK status code with a JSON object confirming the deletion..

{
    "code": "200",
    "status": "All music track entries in the project have been successfully deleted.",
    "timestamp": "2025-01-01T19:10:00Z"
}

Error Responses

Error responses will typically include an appropriate HTTP status code and a JSON body with an error message.

{
    "code": "404",
    "status": "The project with the chosen projectId could not be found.",
    "timestamp": "2025-01-01T19:10:00Z"
}

Endpoint URL

Endpoint URL to convert a sequence into a music cue sheet document in one step.

https://api.editingtools.io/v2/cuesheet

Endpoint URL to create and manage a music cue sheet project.

https://api.editingtools.io/v2/cuesheets

Authentication

This API requires Basic Authentication. The "Authorization" header should be set with the Base64 encoded string of "apikey:YOUR_API_KEY".

Authorization: Basic <base64Encoded(apikey:YOUR_API_KEY)>

Data Handling

Request parameters must be UTF-8 encoded. Results are returned as UTF-8-encoded JSON. By default, datasets will be inside the data tag.

Error Handling

This API service uses standard HTTP response codes to indicate whether a method was completed successfully. HTTP response codes in the 2XX range indicate success. Responses in the 4XX range indicate some sort of failure, while responses in the 5XX range indicate an internal system error that cannot be resolved by the user. The following error codes are used by the API:

Rate Limits

To prevent abuse and spam, the API has limits at various levels. If you receive error code 429 (Too Many Requests), it means you have reached a rate limit.

If you receive a rate limit error, you should stop making requests temporarily. If the retry-after response header is present, you should not retry your request until after that many seconds has elapsed. To prevent rate-errors, we recommend to wait 300 ms to 800 ms between requests to the same endpoint.

Also there is a general limit to the api and all requests made:

The general limits per minute and per hour can be changed upon request.

Upload Limits

The maximum upload size for any single request — including file uploads — is 100 MB. This is a hard limit and applies regardless of your API plan or usage level.

If your request exceeds this size, it will be rejected before reaching our servers. To ensure successful uploads:

• Make sure uploaded files are under 100 MB.
• For larger media, consider splitting files before upload.
• Requests close to the limit may still fail due to encoding or header overhead.

Timezone

This API endpoint returns the time as an ISO 8601 timestamp in the UTC time zone. These timestamps look like 2025-01-10T15:05:06Z.

Localization and Languages

This API supports multiple languages. For instance, it can display the text of a status message in a different language.

Accept-Language: LANGUAGE

Example

To set the preferred response language to Spanish, add this header:

Accept-Language: es

cURL Example

To apply the language in a cURL request, add the following header:

-H "Accept-Language: es"

Available Languages

The following list contains all the currently available languages. Note that setting a language header does not guarantee a translated response, as not all texts are translated. If no language is set or a translation is unavailable, the default response will be in English.
